working width: 1m, 1.5 m, 2m, 2.5 m, 3M, etc.
In stock single or double:
the slatted bar rink,
spiral-slatted skating rink,
Depth of processing: 3-5 cm
drum Diameter: 320 mm / 270 mm.
the Number of knives drum: 8 PCs
The knife on the drums:
the with a rectangular cross section,
the location of the knives on the drum:
Feature spiral-slatted rollers is helix working the plate.
When working strap rink is into the ground at an angle of 17° relative to the axis of the rink, and it comes out close to horizontal.
the Rink is not clogged with earth and plant residues.
the Shape of knives:
All rollers are equipped with universal brackets for attachment to various types of frames, allows you to operate the rink with various cultivators and harrows, as well as additional equipment spring or Daisy chain harrows.
When working is podkovka part of the ground replicate which are cut weeds and crop residues, it remains only to smooth the treated surface of the field.
Thanks to calculated the helix angle of the working strap rinks, the soil is thrown back and to the side, thereby improving the microrelief of the field.
