Indicator

Value

12.25

Working width, m:

12

Working length, m:

9.8

Transportation length, m:

8

Transportation height, m:

3.98

Transportation width, m:

3

Total weight, t:

14.5

Number of coulters:

48

Coulter spacing, cm:

25

Number of coulter rows:

1

Seed/fertilizer placement depth, mm:

20-85

Depth adjustment

Set of clips 50/30/19/10/7 mm

on hydraulic cylinder rods

Hopper capacity 60/40, l:

7000

Seed, l:

4200

Fertilizer, l:

2800

Application rate min/max

seeds, kg/ha:

1/350

fertilizer, kg/ha:

3/350

Seed/fertilizer rate adjustment:

Electric motors

Tire sizes

Feed hopper:

650/65-30,5 16PR FLOTATION 648

Frame:

380/55-17 STARCO FG FLOTATION

Tire pressure (feed hopper), bar:

2.2 – 2.6

Tire pressure (frame), bar:

2.8 – 3.2

Tractor hitch:

Two-point hitch KAT3

Hydraulic requirement

lifting/lowering:

1 double-acting spool valve

Folding/unfolding:

1 double-acting spool valve

Fan drive:

1 double-acting spool valve

Hydraulic pressure, bar:

180

Brake system (optional):

Pneumatic

Minimum tractor pulling power, hp:

230

For deep tillage it is recommended, hp:

250

Number of operating personnel, persons:

1
